MagCore Plus II - Accessories; Before Installation

6
MagCore® Plus II
Accessories
Installation
1. T-Rack X 1
2. Cartridge Rack X 1
3. Power Cable X 2
(Europe standard and U.S.A standard)
4. Grease X 1
5. 3mm O-Rings X 16
6. 5mm O-Rings X 16
7. Empty Cartridge X 10
8. Sample Tube /Elution Tube X 20
9. Pipette Tip X 20
10. Waste Box X 1
11. Barcode Scanner X 1
Please refer to the machine size shown in the above figure to prepare an appropriate position for the machine and
reserve space for thermal dissipation.
1
2
3
4 5
7
6
8 9
10 11
━ Before Installation
605 mm
Left Side (Keep space clear)
Height (Keep space clear)
602mm
523mm
Depth
Width
