26054810 1,5 +1,5 Mt EXTENSION FENCE + N° 4 ROTARY STOPS UNIT
26050801 ROTARY STOP UNIT
POS. CODE P
ART NAME QUANTITY
1 00000150 SELF LOCKING NUT M10 UNI-7473 4
2 00003921 SNAP LEVER KRB 6356020 M8 4
3 00004020 SNAP LEVER ART 523-65 M8x40 4
4 00005127 SELF TAPPING SCREW TC Ø2,2x6,5 ISO1481 8
5 00018456 SCREW VTSTEI 6x35 PP 4
6 00018500 NUT M6 UNI-5588 4
7 00018521 WASHER Ø8 UNI-6592 8
8 00018522 WASHER Ø10 UNI-6592 4
9 00150808 SCREW VTSTEI M8X20 8
10 36000079 THREADED PIN 4
11 36001176 FENCE SECTION BAR 1,5 Mt 2
12 36003078 ALIGNMENT PIN 2
13 36050801 DOWEL 4
14 36050802 STOP HOLDER 4
15 36051803 ROTARY STOP 4
16 36054612 LOCATING BLOCK 2
17 36054805 RH MILLIMETRED RULE 0-1500 1
18 36054806 LH MILLIMETRED RULE 0-1500 1
19 36054807 LH MILLIMETRED RULE 70-1500 1
20 36054808 RH MILLIMETRED RULE 70-1500 1
SHEET 11
