Magicard 360 NEO - Replacing the Printhead

360 NEO Card Printer – User Guide
36
Replacing the Printhead
Refitting a replacement printhead is the reverse
order
of the procedure below.
Remove connector from
rear of printhead
1
2
3
Gently push to
release printhead
Tilt printhead clear of
mounting
4
5
Lift printhead from
mounting
