MAGICFX® SPARXTAR — User and Installation Manual 15
3.2 MOUNT ON A TRUSS
NOTICE
Use a MAGICFX
®
BASEPLATE II for mounting on top of an upright
truss, see the User and Installation manual of the MAGICFX
®
BASEPLATE II (PART01575).
1 Screw two clamps into threaded holes on the bottom of the machine. Use two
M10 twenty clamps for truss mounting (product code MFX3103) and place the
pair in x or in y direction.
Y
Z
X
Y
Z
X
