Magicfx SPARXTAR SPARK FX - Technical Data

6 MAGICFX® SPARXTAR — User and Installation Manual
CAUTION
Do not ll the hopper with anything else than the prescribed
powder. Use of any other powder or substance could lead to
injuries and damage.
Code 
MFX5101 MAGICFX
®
SPARXTAR Powder
Type of powder
1.3 TECHNICAL DATA
Product Product Name
MAGICFX
®
SPARXTAR
Product Code
MFX5001
Product Type
SPARK FX
Main

Length (mm/in.)
300 11.8
Width (mm/in.)
318 12.5
Height (mm/in.)
243 9.6
Weight Empty weight (kg/lb.)
11.7 25.8
Package Length (mm/in.)
416 16.4
Width (mm/in.)
416 16.4
Height (mm/in.)
333 13.1
Packaged weight (kg/lb.)
12.5 27.6
 Minimum Temperature (ºC/ºF)
-10 14
Maximum Temperature (ºC/ºF)
50 122
Humidity (Relative)
20% to 90% (non condensing)
Electrical Voltage Input (Vac)
220-250Vac
Voltage Frequency
50-60Hz
Power Consumption (Vac)
350W
Power Connector (Vac)
Neutrik
®
powerCON TRUE1 (in&out)
Controlling Control Options
DMX
Control Protocols DMX512-A (ANSI E1.11)
RDM (ANSI E1.20)
Control Connectors
Neutrik
®
5-pole male/ female XLR
 Congure Options
On Device & RDM
Usage Consumable(s)
MAGICFX
®
SPARXTAR Powder
Consumable Consumption
< 20 g/min
Technical data
