BASIC RECORDING & ONE-TOUCH TIMER RECORDING
If
y
ou are recording to the HDD, press
[
HDD
]
first
,
then
p
rocee
d
to ste
p
2
.
I
f
y
ou are recording to a disc, press
[
DVD
]
f
ir
st.
1
Insert a recordable disc (re
f
er to pa
g
e
27 on
h
ow to insert a
d
isc
).
Align the disc to
the disc tray guide.
* Ma
k
e sure t
h
e
d
isc is com
p
ati
bl
e wit
h
t
h
is unit.
(Refer to pa
g
e 41 for the list of compatible discs.
)
It may ta
k
e a w
h
i
l
e to
l
oa
d
t
he disc data a
f
ter the disc tray closes.
• When insertin
g
a brand-new DVD+RW/DVD
-
R
W, the unit automaticall
y
starts to format.
(
Except when HDD is recordin
g
, or when there
is a timer pro
g
ram which starts in 15 minutes.
)
• I
f
titles have been recorded on the disc
,
the
tit
l
e
l
ist is
d
isp
l
aye
d
. Press
[
ST
O
P
C
]
to
e
xi
t
the
t
i
tle
l
i
st.
2
Press [REC MODE] repeate
dl
y to
se
l
ect a recor
d
ing mo
d
e
.
Refer to “Recordin
g
Mode” on pa
g
e 42.
DVDSP(2Hr) 0h58m
3
Select the a
pp
ro
p
riate external in
p
ut
c
h
anne
l
by
pressing [SOURCE] or
[
CHANNEL
/
]
.
Press [DTV/TV] to se
l
ect ana
l
o
g
TV or
di
g
ital TV, then use [CHANNEL
/
]
or [the Number buttons] and [ • ]
(f
or
di
g
ital TV channels) to select a
d
e
s
ire
d
ch
a
nnel t
o
rec
o
r
d.
Re
f
er to “Switching Analog Mode/Digital Mode”
an
d
“C
h
anne
l
Se
l
ection“ on page 35
.
CH 12
F
o
ll
ow t
h
e steps to recor
d
TV programs.
E2S02UDMDR515HF7ENv1.indd44E2S02UDMDR515HF7ENv1.indd44 2010/08/179:04:542010/08/179:04:54

Magnavox MDR515H Specifications

Power

power supply voltage	120 V
power supply frequency	60 Hz

Ports & Interfaces

front connections	Analog Audio Left/Right In, Composite Video (CVBS) In, DV In, S-Video In
rear connections	Analog audio Left/Right out, Component Video output, Composite video (CVBS) output, Digital coaxial out, HDMI output, S-Video out, Analog audio Left/Right in
additional rear connections	Composite video (CVBS) input, S-Video in, RF In, RF Out

Weight and Dimensions

set dimensions	420 x 59 x 290 mm
set weight	3.4 kg
packaging dimensions	520 x 147 x 413 mm
weight including packaging	4.6 kg
