Note 1
With the BCD models four different settings can be stored
in memory. The operations are as follows.
A CH CPH1 CPH2 CPH3 CPH4
CPL1 CPL2 CPL3 CPL4
↓↓↓↓
B CH CPH1 CPH2 CPH3 CPH4
CPL1 CPL2 CPL3 CPL4
• When the 4 settings are not required press
COMP
repeatedly.
• Changing the 4 different setting values is carried out via
the BCD connector input terminal.
• When the BCD connector is not connected the setting is
CPH1 and CPL1.
Note 2
If
SET
is not pressed the previous setting is maintained.
Note 3
When the
SET
key is pressed to set the CPL the sign (“+”
or “–”) of the CPH value may flash. This is because the CPH
(upper limit) is less than the CPL (lower limit), and the
device is in the CPH setting mode. In this case, return to
and start from the CPH setting.
3 Push
SET
to set.
“CPH” flashes.
4 Push
COMP
to select the CPL comparator lower limit
setting mode. Sign of the CPL value flashes.
5 Same as 2.
6 Push
SET
to set.
“CPH” and “CPL” flash.
7 Push
COMP
to select the mode for setting the channel B
comparator values.
∗ Single channel models return to the measuring state.
8
9
10 Same as 2, 3, 4, 5, 6.
11
12
13 Push
COMP
to return to the measuring state.
