Magnum MS2000 - Figure 1-4, Left Side Features (MS2000 Series)

Page 6
© 2016 Sensata Technologies
Introduction
Figure 1-4, Left Side Features (MS2000 Series)
15
AC Access Cover
AC Input Circuit Breaker
AC Output Circuit Breakers
(on -15B, -20B output
breaker models only)
16
17
Note: The model shown is not a -15B or -20B model, therefore it does not show any AC output
breakers. Models without output breakers (CB1 & CB2) use carriage bolts to fi ll the breaker openings.
