Step 4
 Turn ignition OFF
 Diagnostic connector
DISCONNECTED
 Check continuity
between terminals 4,5
and battery negative
terminal
Does continuity
exist?
YES
NO
 Turn ignition OFF
 ECU connector
DICONNECTED
 Check continuity between
terminal 7 of Diagnostic
connector and terminal 64 of
ECU connector.
 Turn ignition OFF
 Repair / replace wiring
harness between terminals
4,5 and battery negative
 Clear error codes
Does continuity
exist?
YES
NO
Go to Step 5
 Turn ignition OFF
 ECU connector
DICONNECTED
 Repair / replace wiring
harness between terminal 7
of Diagnostic connector and
terminal 64 of ECU
connector

Clear error codes
Step 3
