Mahindra Maxximo Mini Van Vx 2012 - Page 208

Diagnostic Manual MAN-00183
MAXXIMO MINIVAN VX June 2012/Rev 1
The reproduction, translation, transmission, in part of or whole of the present document are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any
person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution. © 2012 Mahindra &
Mahindra Ltd.
208
 Ignition OFF
 Cam phase sensor connector
DISCONNECTED
 ECU connector CONNECTED
 Check the continuity between
pin 3 and pin 1 of the cam
phase sensor connector
Step 6
Does continuity
exist?
YES
Go to step 7
Is voltage 4.7 to
5.25V?
YES
N
O
Step 5
 Turn ignition OFF
 Cam phase sensor connector
DISCONNECTED
 Turn ignition ON
 Measure the voltage between
pin 3 of the cam phase sensor
connector and battery
negative
 Ignition OFF
 Check for any loose
connections or pin
oxidation in the cam
phase sensor connector
 Clear the error codes and
verify
Go to step 8
N
O
