Does continuity
exist?
N
O
 Suspect ECU
 Contact TEKliner
YES
 Ignition OFF
 Cam phase sensor connector
DISCONNECTED
 ECU Connector
DISCONNECTED
 Check the continuity between
pin 3 of cam phase sensor
connector and pin 45 of the
of ECU connector
Step 8  Ignition OFF
 Examine the short circuit of
reference voltage line to
ground line.
 Repair/replace the wiring
harness
 Clear the error codes and
verify
Step 7
 Ignition OFF
 Examine the open circuit of
reference voltage line
 Repair/replace the wiring
harness
 Clear the error codes and verify
