Does continuity
exist?
Go to Step 5
 Ignition OFF
 Cam phase sensor connector
DISCONNECTED
 ECU Connector
DISCONNECTED
 Check the continuity between
pin 3 of cam phase sensor
connector and pin 45 of the
of ECU connector
Step 4
Go to Step 5
 Ignition OFF
 Examine the short
circuit of reference
voltage line to ground
line.
 Repair/replace the
wiring harness
 Clear the error codes
and verify
Step 3
N
O
 Ignition OFF
 Examine the open circuit
of reference voltage line
 Repair/replace the wiring
harness
 Clear the error codes and
verify
 Suspect ECU
 Contact TEKliner
YES
