Lc filter Standard Standard cutoff (as per ISO, JIS, ANSI/ASME).
Short Next shortest cutoff.
0.8 mm Fixed cutoff.
Lc
mm
Cutoff freely defined.
Drive On Drive unit of MarSurf PS 10 is switched on.
Off Drive unit of MarSurf PS 10 is switched off (e.g. when
the measuring object is moved by a third-party drive).
The third-party drive must be set to the selected
measuring speed.
Measuring speed 1.0 mm/s
0.5 mm/s
Measuring speed at which the drive unit moves the
probe over the measuring object.
Probe type 350 µm
150 µm
100 µm
Measuring range of the probe used.
Calibrate
Calibrates the probe (see Section 3).
Parameters
Ra
Rq
…
Activated parameters will be evaluated.
Tolerance limits
Ra 0.000 0.000
…
Lower and upper tolerance limit for each parameter.
Parameter
settings
C1
µm
C2 µm
Upper section level C1 and lower section level C2 for
evaluating RPc and RSm.
C1 / C2
Rz / 10
Vertical counting threshold for evaluating RSm.
CREF
%
Reference line evaluating the material ratio Rmr or tp.
C
µm
C µm
C µm
Section level for three possible material ratio values
Rmr or tp.
MOTIF settings
Filter
A
mm
B mm
Operators A and B for maximum length of roughness
motifs / waviness motifs.
Arguments
Scr1
%
Scr2 %
Upper and lower intersection line for zone width CR
of the profile peak zone.
Scf1 %
Scf2 %
Upper and lower intersection line for zone width CF
of the profile core zone.
Scl1 %
Scl2 %
Upper and lower intersection line for zone width CL
of the profile valley zone.
