Mahr GmbH, MarSurf PS 10
Export settings
Export Measuring results
Profile
Record (PDF)
Select the content to be saved. It can be saved
automatically or using the
button.
The files are saved in the internal memory or on a
micro SD card (if a micro SD card is in the slot) in the
following folders:
− "Export" for measuring results in CSV format,
− "Profiles" for profiles in TXT or X3P formats,
− "Records" for measuring records in PDF format
(see also Section 5.1).
Automatic The activated contents are saved automatically after
every measurement.
Export file for
measuring results
Replace The results of a measurement are exported to
the "Results.csv" file; the results of the previous
measurement are overwritten.
Append The results of a measurement are exported to the
"Results.csv" file and written below the existing
results of previous measurements.
Export file for profile TXT
X3P
Format of profile file: Text file (*.txt) or file as per
DIN EN ISO 5436-2 (*.x3p).
Lock
Users can enter a code number of their choice
between 0 and 9999 to lock the settings of the
MarSurf PS 10.
The code number must be entered again to unlock
the settings.
Basic view
Basic view for the evaluation (horizontal to the left,
horizontal to the right, vertical, results only).
Power options
Dim the screen after 10 s
30 s
Never
Idle period after which the screen is dimmed and
locked.
Tap the screen to light it up again.
Tapping the
gh
symbol unlocks the screen.
Enable sleep mode
after
30 s
5 min
Never
Idle period after which the MarSurf PS 10 goes into
sleep mode (unless the AC adapter is connected).
When you press the green Start key the instrument
will return to operating mode.
Switch off after 15 min
30 min
Never
Idle period after which the MarSurf PS 10 switches
off (unless the AC adapter is connected).
