Operation Manual easyTymp
8111254 Rev. 9
17
17/01/2018
Cleaning alternative:
Figure 9
Figure 10
Use the cleaning set from the eartip box (Figure 9):
Take the cleaning tool apart to find the thin brush
and thin rigid plastic cord (Figure 10).
Figure 11
Use the plastic cord or brush to push debris out of
the probe tip (Figure 11).
Figure 12
Always enter the probe tip from the rear to avoid
accumulation of debris inside the vents (Figure 12).
Figure 13
This procedure destroys
the probe (Figure 13).
Figure 14
This procedure destroys
the probe (Figure 14).
CAUTION
CAUTION
