Operation Manual touchTymp MI 26 and MI 36 Version
8511780 Rev. 4
43
30/06/2021
Figure 52
The stimulus selected upon entering the Edit screen is
always the first reflex performed. A red or blue line will
outline the selected box based on which ear is selected
(Figure 52).
NOTE: The direction of deflection can be modified in the
in the Settings menu. See section 5.6.9.
Figure 53
The large window displays multiple reflexes performed for the
selected stimulus. Up to the last five reflexes are displayed.
Intensity level and deflection value are displayed below each
reflex graph (Figure 53).
The bottom row of the display provides result information
for the highlighted reflex (i.e. stimulus: 500 Hz Ipsi,
deflection value: .08 ml, intensity: 90 dB HL)
Editing the displayed reflex
Figure 54
To change the reflex level, touch the column where the
graph is displayed. This will move the highlighted box to
the new level and place the result in the small box on the
right (Figure 54).
Figure 55
When a Pass or No Response is displayed, the
examiner can change this by touching the highlighted
column. This will toggle the notation with each touch.
(Figure 55).
IMPORTANT NOTE: Careful review should be taken when making changes to
automatic threshold results.
To return to the test module, select the Edit button from the tool bar. All changes
are saved for printing and/or transferring to the PC upon exiting the edit mode.
