MAKELSAN BOXER SERIES - Page 54

BOXER SERIES 10-20 KVA EXPLANATIONS OF LOGGING
AG-SD-109 Publishing Date: 13.10.2015 Revision No: 0 Rev. Date:
62
Test
Mode
UPS has switched to battery test mode, loads are energized
through rectifier- battery- inverter line as source sharing.
63
Switch to Inverter
Mode
Switching to inverter mode command has been given via front
panel.
64
Output Voltage
Error
Output voltage is detected during the period of starting UPS. UPS
has been stopped.
65
PFC Stop Command
Abnormal situation is detected during the moment of rectifier
operating. UPS has given a command to stop itself.
66
Start Command
Start command is given via UPS command menu.
67
Stop Command
Stop command is given via UPS command menu.
68
UPS Stopped
UPS has been stopped.
69
Bypass
Error
UPS has switched to bypass mode so many times in a short
period, UPS will be shut down.
70
Parameters Changed
Device-related parameters were changed on the service menu.
71
Battery Changed
Battery replacement date has been changed. Battery statistics will
be reset.
72
Load Impact
Transfer
The load which cannot be handled by inverter is activated. Loads
will be transferred to bypass line.
73
Parallel Command
An UPS which is operating in parallel mode has been given a
command to change the status of static switches.
74
No Parallel CAN
Bus
Communication
Slave UPS which is operating in parallel mode can’t reach to
master UPS from CAN bus. If UPS is operating, will be shut down.
75
Externally Start
Command
UPS which is operating in parallel mode has been received a
command to start up by another UPS.
76
Externally Stop
Command
UPS which is operating in parallel mode has been received a
command to stop by another UPS.
77
Externally Switch To
BYPASS.
UPS which is operating in parallel mode has been received a
command to transfer the load to bypass line.
78
Externally Switch To
UPS
UPS which is operating in parallel mode has been received a
command to transfer the load to inverter.
79
Parallel
Communication FE
Error
Slave UPS which is operating in parallel mode has detected a
failure of input current sharing.
80
Inverter OKEY
Inverter voltage reached needed value after UPS is started up.
UPS can feed the loads through inverter.
81
Abnormal Battery
Temperature
Battery temperature is out of defined limits, batteries can be
damaged.
82
EPO key pressed
EPO button is pressed.
83
Low Battery
Battery capacity has decreased below defined battery low limit
while UPS was operating in battery mode.
84
No Parallel 485
Communication
No RS485 communication between the parallel systems is
available.
85
STS Over Current
Time of over load in Bypass line is up.
86
BYPASS Phase
Reverse phase sequence was detected in mains at the UPS run
