BOXER SERIES 10-20 KVA EXPLANATIONS OF LOGGING
AG-SD-109 Publishing Date: 13.10.2015 Revision No: 0 Rev. Date:
Sequence Error
time.
87
Output DC Voltage
Error
Inverter DC voltage limit has been exceeded. Loads will be
transferred to the bypass line.
88
Output Offset Error
One or more phases of slave devices’ output is not connected to
master device in parallel systems.
89
Normal Battery
Temperature
Battery temperature is within limits.
90
PFC Pbus Over
Voltage
Positive bus voltage limit excess.
91
PFC Nbus Over
Voltage
Negative bus voltage limit excess.
92
PFC FL1 Over
Current
Short circuit protection is activated in rectifier L1 phase.
93
PFC FL2 Over
Current
Short circuit protection is activated in rectifier L2 phase.
94
PFC FL3 Over
Current
Short circuit protection is activated in rectifier L3 phase.
95
Single Stop
Command to stop itself has been given to UPS which is operating
in parallel mode separately from parallel system.
96
Master
Changed
UPS became master device in parallel system.
97
Parallel ID
Coincidence
ID values of one or more device are the same as each other in
parallel system.
98
Stop All
Stop the whole parallel unit command was given via front panel.
99
Power Supply Error
An error signal is detected through power source circuit
debugger.
100
Generator
Mode
Signal is detected from generator mode input of dry contact
board. UPS will switch to generator mode.
