THE REPLICATOR™ DIAGRAM
Before we continue, let’s familiarize ourselves with some of the main features of The Replicator
BACK
1. Power switch
2. Power input
3. USB-B input
4. Reset button
5. Right and left spool holders
FRONT
1. Single or Dual Stepstruder
®
MK8
(attached to mount)
2. Build Platform
3. LCD Interface Panel
4. Filament Guide tubes
5. SD Card slot (on side panel)
