Insert the pin to prevent the NYLON CUTTING HEAD ASS'Y(140) from rotating.
DISASSEMBLY & ASSEMBLY PROCEDURES
(Common in EM2600U, EM2600L and ER2600L)
Precautions in Disassembly & Assembly
Disassembly
1.Handle disassembled parts with care, and clean and keep them in order.
2.Clean off mating surfaces of removed packing components.
Assembly
1.Note assembly order (and assembly direction).
2.Replace packing/gaskets as required.
3.Check operation and sound after assembling key parts.
