Focusing Screen N
Viewfinder Contact
This electric
contact
is used
to
Aperture Ring Couping Pin
This pin is fitted into the
Expos
Meter Coupler of the lens, to
transmit the
aperture
data to the
AE Prism Finder.
exchange data with AE Prism
Finder.
Hot-shoe
(X
contact)
A cordless flash can be used with
this
shoe.
Alignment
Dot/Battery
Check
Lamp
Flash Sync Terminal
A flash bulb, flash
synchro
card
Shutter Release Selector
A white square is used d
normal photography. When
dot is
indicated.
the
shutl
locked, turning power OFF.
When the
battery
is exhausted,
the mechanical shutter can be
released at
approx.
1l/60 second
when this selector is aligned
with
the yellow dot.
and optional synchro terminal
adapter
can
be connected with
this terminal.
Mirror Lock-up Lever
Neck Strap Lug
Auxiliary Release Contact
When the
cover
is moved to the
left the
contact
appears. This
Shutter Release Button
contact is
used
for connections of
external releases such as a
spe-
Focusing Screen Release Pin
When you want to change the
screen, slide this
pin to the
left
and
remove
the screen.
cial hand grip and remote
control
unit.
Lens Release Button
*Never touch the surface of the
mirror.
Battery Check Button
LED displays the present battery
condition
.
5
