Areas of Viewfinder Field to be Composed
When using Roll Film Holder
When composing the 6
x
9 or 6 x 7 format with
the viewfinder frame, employ inside edges of the
frame for subjects at close distance; use the
outer edges of the frame for subjects further
away.
Distance Range Composed by Brilliant
Frame
Focal length
of lens
100mm
:;;;
150mm
f/5.6
250mm f/5
I
For close ranges,
use inside
edges of frame
3.5ft to approx. 6ft
(1m)
(2m)
6ft.
to approx. 9ft.
(2m) (3m)
For distances further
away, use outside
edges of frame
approx. 6ft. to infinity
(2m)
approx. 9ft.
to infinity
(3m)
approx. 12ft. to infinity
(4m)
The 250mm f/5 lens interlocks with the range-
finder from distances of 20 ft (7m) to
CO
(infinity).
When photographing with the 6 x 6 format or
6
x
4.5 format by employing the roll film holder
model K, use the attached finder mask. See page
24 for details.
6x9
6x7
For close range
For close range
For distances further away
For distances further away
12
