Removing and installing vibration damper,
changing front crankshaft seal
59
Changing front crankshaft seal
Fig. 5
Remove cover (13 mm).
Replace front crankshaft seal only as a complete
unit, i.e. race and radial shaft seal.
Fig. 6
To remove the race, a puller (special tool, see
page 127, item 13) is necessary.
Fig. 7
Pull off race.
Fig. 8
Special tools are required for installing the race
(see page 127, item 15).
Clean inner side of race and crankshaft stub. Coat
crankshaft stub with sealing agent ”Antipor 46”.
D Push race Æ and pressing sleeve Ç onto
adapter Â.
D Tighten spindle À in adapter  with nut Ã.
D Bolt adapter  to crankshaft.
3479
2718
3480
3091
