8
2.4.1 Balance Tilt Axis
2.4 Gimbal Balancing
(1) a. Unlock the tilt axis position lock ①, turn the camera lens upwards, and
check the gravity center of camera.
b. Loosen the sliding arm lock screw ②, slide the sliding arm ③ to balance the
camera.
c. Tighten the sliding arm lock screw ②, when the camera lens keeps upwards
that means balanced.
1) Before balancing the Gimbal, please lock the Gimbal at the balanced lock
status.
2) Lens cover should be removed from the camera and the memory card
needs to be inserted to the camera to complete all the connections to ensure
that the camera is ready for shooting.
3) When balancing the Gimbal, make sure the camera and Gimbal are all
powered off.
4) If it is needed to add accessories after the balance is completed, Gimbal
needs to be re-balanced again.
TIPS
