B - BASKET COMMAND AND CONTROL STATION
21 - EMERGENCY STOP
22 - OVERLOAD LAMP AND VARIATOR DEFECTS
23 - SLOPE LAMP
24 - SOUND ALARM HORN
25 - CONTROL SWITCH
26 - CONTACTOR OF SELECTION OF ROTATION
27 - PLATFORM INCLINATION CONTACTOR
28 - EXTENSION ARM LIFTING / LOWERING CONTACTOR
29 - TELESCOPE OUTPUTS / INPUTS CONTACTOR
30 - SUPERIOR ARM LIFTING / RAISING CONTACTOR
31 - INFERIOR ARM LIFTING / RAISING CONTACTOR
32 - TRAVELLING CONTACTOR
33 - ALARM BUZZER
34 - SAFETY HARNESS ATTACHMENT POINTS
35 - CONSOLE PROTECTIVE COVER
NB: The terms RIGHT-LEFT-FRONT-REAR apply to a user on the nacelle platform in the transportation position
and looking straight ahead.
