2 - 43
PROCEDURE OF FREE WHEELING
The platform may only be towed a short distance and only by a machine with
significant braking performance, in order to hold it: the two machines must be
connected by a tow bar.
- To set the platform to free wheel, it must not be subject to any
travelling stresses from slopes. The wheels must be able to turn
freely.
- If possible, raise the platform to free the drive wheels in order to
facilitate the operation.
- Loosen bolt 1 (Fig. F) on each wheel 22 mm from the edge, up to
the resistance point, without forcing it (2 daNm) : see (Fig. G).
- The machine can be towed as a trailer.
Warning : do not loosen screws more than 22 mm ; risk of rupture and major
damage to the reducer.
If in doubt, contact your dealer.
RE-INSTALLATION
-
Turn the wheel gently from left to right to reset the gear while
retightening the screws (1) (Fig. F). Pay attention to the torque
when tightening
(15 daNm).
