MEANING
1 - WHITE ARROW
Indicates the translation direction when travelling forwards.
When the turret assembly, the arms assembly and the basket make
a 180° rotation with respect to the chassis, the travelling controls are
reversed.
Identify the forward direction by looking at the arrows on the chassis
and on the basket control console.
2 - BLACK ARROW
Indicates the translation direction when reversing.
Same as for white arrow
NB: As on the basket console and the chassis, the white arrows indicate forward travelling
and the black arrows reverse travelling.
3 - LOAD PER WHEEL
This indicates the maximum load on one wheel and the load the wheel will exert on the
ground (see 2 - DESCRIPTION: CHARACTERISTICS for the piercing value).
Before using the platform, identify the type of ground and find out its
ability to resist being pierced.
NB: The weight must be visible on the platform.
4 - MANUAL CONTROL PROCEDURE
This describes the procedure for: lowering or turning the basket, turning the turret and
directing the wheels using the pump and the manual controls.
XXXX Kgs - XXXX Lbs
