13
DORADO COMP 37MM SERVICE GUIDE
1
IF CHANGING SPRING RATE WITHOUT SERVICE,
ONLY STEPS 1 AND 2 FROM THIS SECTION ARE NECCESARY.
Using a 2mm hex wrench remove the preload adjuster.
on the bottom of the leg.
NOTE: Be sure to hold the knob still while removing the screw.
The damper adjuster may be damaged if the knob is over torqued.
2
3
Using a 20mm socket loosen the bottom spring cap.
Then gently remove the cap and spring by pulling them
out of the leg.
For information of spring rate, see setup guide.
Loosen the pinch bolt on the top crown, and crack the
top cap loose with a 16 notch Bottom Bracket Tool.
SPRING LEG DISASSEMBLY
NOTICE
NOTICE
