26 - FRONT SIDELIGHTS AND WORKING LIGHTS
• A - Front left sidelight.
- Front left working light.
• B - Front right sidelight.
- Front right working light.
27 - FRONT INDICATOR LIGHTS
• C - Front left indicator light.
• D - Front right indicator light.
28 - REAR LIGHTS
• A - Rear left headlight.
Rear left stoplight.
• B - Rear left indicator light.
• C - Rear left reverse light.
• D - Rear right headlight.
Rear right stoplight.
• E - Rear right indicator light.
• F - Rear left reverse light.
29 - FLASHING LIGHT.
30 - WORKING TAIL LIGHT
25 - BRAKE OIL TANK
See: 3 - MAINTENANCE: B - EVERY 50 HOURS OF SERVICE.
2-31
29
B
F
C
E
A
D
30
B
D
A
C
647503 (10/05/2017)
M
E 418/420/425C 48V S3
