Page #67 background imageLoading...
Page #67 background image
2-15
EN
648970 IT-EN-FR (18/02/2016)
ENGINE
Engine
Type OM 934LA,E4-5 (EU Stage IV / US Tier IV)
Fuel Diesel
Number of cylinders 4
Injection system Common rail
Firing orde 1 - 3 - 4 - 2
Displacemen L -cm
3
5,1 - 5100
Bore mm - in
110 - 4.33
Stroke mm - in
135 - 5.31
Turbocharging System Turbocharging with charge air cooling (air/air)
Compression ratio 17,6
Nominal rate rpm 2200
Idle rate rpm 800
Maximum idle rate rpm 2500
Rating (ISO/TR 14396) 115 kW @ 2200 rpm
Maximum torque 675 Nm @ 1200 - 1600 rpm
Main Coupling type SAE3
Additional service PTO (type, max torque) PTO 1: 110 Nm
Aftertreatment type
SCR system, exhaust muffler with catalyst, AdBlue injection with
supplying and metering unit
Alternator 24 V - 100 A
Supplier installation approval YES
Cooling system
Water cooling Water radiator with hydraulic motor
Hydraulic Oil cooling Electric hydraulic oil radiator
Air cooling system (intercooler) Air radiator with hydraulic motor
Fan drive system
Motor type Hydraulic
Blower fan speed rpm 2300
Number of blades 14
Diameter mm - in
680 - 26.77
Thermostat - -
Opening start deg. 83
Complete opening deg. 95
ELECTRICAL CIRCUIT
Electrical circuit
Ground Negative
Battery standard N°2 12V 120 Ah-850 A EN
Battery optional N°2 12V 180Ah 1200A(EN)
Voltage regulator CONVERT. DC-DC 24-12V 20A
Starting V./AMP
Engine Starter type STARTER MOTOR REMY 29 MT, 24 V, 3,9 kW
Engine Alternator datas ALTERNATOR 28V 100A
HYDRAULIC CIRCUIT
Main hydraulic pump
Pump Type External Gear Pump
Displacement L - cm
3
0.05183 - 51,83
Flow rate @ xxxx rpm l/mn 114
Pressure bar - psi 270 - 3916.019 (peak pressure)
TECHNICAL SPECIFICATIONS
