Manitou MT 1435 EASY 75D ST3B S1 User Manual

3 - 9
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,P = BLEED,
R=REPLACE, V = DRAIN
PAGE (1)
DAILY OR EVERY 10
HOURS OF SERVICE
EVERY 50 HOURS OF
SERVICE
EVERY 250 HOURS
OF SERVICE
EVERY 500 HOURS
OF SERVICE OR
EVERY YEAR
EVERY 1000 HOURS
OF SERVICE OR
EVERY TWO YEARS
EVERY 2000 HOURS
OF SERVICE OR
EVERY TWO YEARS
EVERY 4000 HOURS
OF SERVICE
OCCASIONAL
- Hydraulic circuit pressures C (3)
BRAKE
- Brake oil level 3-18 C C
- Brake oil V (3)
- Brake system P (3)
- Brake system pressure C (3)
- Brake A (3)
STEERING
- Steering C (3)
- Steering swivel joints C (3)
CAB
- Windscreen washer liquid level 3-18 C C
- Cab ventilation filters 3-19/20 R NR
-
Condenser core (Air-conditioning OPTION) 3-19 C/N C/N
- Seat belt 3-30 C
- Condition of the rear view mirrors C (3)
- Structure C (3)
- Air conditioning (OPTION) 3-34 N/C
ELECTRICITY
- Longitudinal stability limiter and warning device 3-12/37 C C XXX
- Condition of wiring harness and cables C (3)
- Lights and signals C (3)
- Warning indicators C (3)
- Front headlights 3-38 A
- Battery failure 3-38 R
FRONT AXLE
- Front wheel reducing gear pivots 3-16 G G G/C (3)
- Front axle oscillation (OPTION) 3-16 G G G/C (3)
-
Front axle differential oil level 3-21 C
- Front wheel reduction gear oil level 3-21 C
- Front axle differential oil 3-25 V V
-
Front wheel reduction gear oil 3-30 V V
-
Wear of front axle brake discs C (3)
- Front wheel reduction gear universal joint C (3)
- Front wheel reduction gear clearance C (3)
REAR AXLE
- Rear wheel reducing gear pivots 3-16 G G G/C (3)
- Rear axle oscillation 3-16 G G G/C (3)
-
Rear axle differential oil level 3-21 C
- Rear wheel reduction gear oil level 3-21 C
- Rear axle differential oil 3-25 V V
- Rear wheel reduction gear oil 3-30 V V
-
Wearing of rear axle brake discs C (3)
- Rear wheel reduction gear universal joint C (3)
- Rear wheel reduction gear clearance
C (3)
FRAME
- Levelling corrector (OPTION)
3-16 G G
- Stabilisers
3-16 G G
-
Structure
C (3)
- Bearings and articulation rings
C (3)
ATTACHMENTS
- Single side-shift carriage (TSDL) (OPTION)
3-16 G G
-
Fork wear
C C (3)
- Attachment carriage
C (3)
- Condition of attachments
C (3)
LIFT TRUCK
- Towing the lift truck
3-39 XXX
- Sling the lift truck
3-39 XXX
- Transport the lift truck on a platform
3-40 XXX
647563 (22/08/2017) MT 1435/1440/1840 EASY 75D ST3B S1
