Manitou MT 1435 EASY 75D ST3B S1 User Manual

3 - 10
A - DAILY OR EVERY 10 HOURS OF SERVICE
A1 – ENGINE OIL LEVEL
CHECK
Place the lift truck on level ground with the engine stopped, and let the oil settle in
the sump.
- Open the engine bonnet.
- Pull out dipstick 1.
- Clean the dipstick and check the correct level between the two notches.
- If necessary, add oil (see: 3 - MAINTENANCE: LUBRICANTS AND FUEL) through the
filler port 2.
- Visually check that there is no leakage or seepage of oil in the engine.
A2 – COOLING LIQUID LEVEL
CHECK
Place the lift truck on level ground with the engine stopped, and allow the engine to cool.

IMPORTANT

To avoid any risk of spraying or burning, wait until the engine has cooled down before removing the cooling circuit
filler plug.
If the cooling liquid is very hot, add only hot cooling liquid (80°C).
In an emergency, you can use water as a coolant, then change the coolant as soon as possible (see: 3 - MAINTENANCE:
F1 - COOLANT).
- Open the engine bonnet.
- The liquid must be at the MAXIMUM level on the expansion tank 1.
- If necessary, add coolant (see: 3 - MAINTENANCE: LUBRICANTS AND FUEL) through
the filler port 2.
- Visually check that there is no leakage in the radiator and pipes.
A3 – FUEL LEVEL
CHECK
As far as possible, keep the fuel tank well filled in order to minimize condensation due
to the atmospheric conditions.

IMPORTANT

Never smoke or approach with a flame during filling operations or when the tank is open.
Never refill while the engine is running.
- Check the fuel gage on the instrument panel.
- If necessary, add diesel (see: 3 - MAINTENANCE: LUBRICANTS AND FUEL).
- Open the access panel for hydraulic oil filling.
- Remove the cap 1 using the ignition key.
- Fill the fuel tank with clean diesel filtered through the filler port 2.
- Refit the cap.
- Visually check that there is no leakage in the tank and pipes.
A4 – FUEL PRE-FILTER
CHECK

IMPORTANT

Carefully clean the outside of the pre-filter and its holder, to prevent dust from getting into the system.
- Open the engine bonnet.
- Disconnect electrical wiring harness 1 from the fuel pre-filter.
- Place a receptacle under the drain plug 2 and unscrew by two to three turns.
- Allow the diesel fuel to flow out until it is free from impurities and water.
- Re-tighten drain plug 2 and reconnect the wiring harness 1.
1
2
2
1
21
1
2
647563 (22/08/2017) MT 1435/1440/1840 EASY 75D ST3B S1
