Manitou MT 1435 EASY 75D ST3B S1 - Mt 1840 Easy 75 D St3 B S1; Visibility

2 - 28
VISIBILITY MT 1840 EASY 75D ST3B S1
Our lift trucks conform to European standard EN15830 with regard to operator visibility.
- Follow the instructions for optimizing operator visibility of the immediate vicinity (see:1 - OPERATING
ANDSAFETYINSTRUCTIONS: INSTRUCTIONS TO THE OPERATOR: DRIVING INSTRUCTIONS UNLADEN AND LADEN: D
- VISIBILITY).
DESCRIPTION AND ADJUSTMENT OF REAR-VIEW MIRRORS
1 - LEFT REAR-VIEW MIRROR
2 - MAIN RIGHT REAR-VIEW MIRROR
3 - CENTRAL RIGHT REAR-VIEW MIRROR
4 - UPPER RIGHT REAR-VIEW MIRROR
5 - REAR REAR-VIEW MIRROR
- Place the lift truck on level ground with the I.C. engine stopped,
and the boom retracted and lowered as far as possible.
- Note the position of the reference points
in the
illustrations, to see and correctly adjust the rear-view mirrors.
1
2
3
4
5
1
5
4
2
3
1
2 4
3
5
