Manitou MT 1435 EASY 75D ST3B S1 - Dimensions and Load Chart; Mt 1840 Easy 75 D St3 B S1

2 - 24
DIMENSIONS AND LOAD CHART MT 1840 EASY 75D ST3B S1
A mm
1200
B
mm
3070
C
mm
2044
C1
mm
1929
D
mm
6274
D1
mm
6159
D2
mm
4894
E
mm
7474
F
mm
1960
F1
mm
1960
G
mm
437
G1
mm
420
G2
mm
433
G3
mm
302
I
mm
1160
J
mm
892
K
mm
1040
L
mm
50
N
mm
1908
O
mm
125
P2
°
37
P3
°
34
R
mm
3779
S
mm
8788
T
mm
4307
U1
mm
2505
U2
mm
2693
V
mm
5592
V1
mm
1285
V2
mm
4009
W
mm
2420
W1
mm
3793
W2
mm
1134
W3
mm
2422
Y
°
12
Z
°
114
D2
B
G2
G1
P2
D
C
W2
C1
D1
A
E
I
N
P3
G
L
Z
Y
U1
U2
F1
F
W
W1
J
W3
G3
S
V
T
V1
V2
R
O
K
647563 (22/08/2017) MT 1435/1440/1840 EASY 75D ST3B S1
