SERVICING SCHEDULE

IMPORTANT

(1): MANDATORY 500 HOUR OR 6 MONTH SERVICE. This service must be carried out after approximately the first 500 hours of operation or within the 6 months following
the start-up of the machine (whichever occurs first).
(2): Every 10 hours during the first 50 hours then a final time at 250 hours.
(3): Contact your dealer.
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,P = BLEED,
R=REPLACE, V = DRAIN
PAGE (1)
DAILY OR EVERY 10
HOURS OF SERVICE
EVERY 50 HOURS OF
SERVICE
EVERY 250 HOURS
OF SERVICE
EVERY 500 HOURS
OF SERVICE OR
EVERY YEAR
EVERY 1000 HOURS
OF SERVICE OR
EVERY TWO YEARS
EVERY 2000 HOURS
OF SERVICE OR
EVERY TWO YEARS
EVERY 4000 HOURS
OF SERVICE
OCCASIONAL
ENGINE
- Engine oil level 3-10 C
- Cooling liquid level 3-10 C
- Fuel level 3-10 C
- Fuel pre-filter 3-10 C
- Dry air filter cartridge 3-14/26 R C/N R
-
Radiator core 3-14 N N
-
Engine oil 3-22 V V
- Engine oil filter 3-22 R R
- Alternator/fan/crankshaft belt tension 3-23 C/A C/A
- Compressor belt tension (Air-conditioning OPTION) 3-23 C/A C/A
- Fuel pre-filter 3-26 R R
- Fuel filter 3-27 R R
- Fuel tank 3-27 N
- Fuel tank breather 3-27 R
- Alternator/fan/crankshaft belt 3-28 R
- Engine silent blocks C (3)
- Engine speeds C (3)
- Valve clearances C C (3)
- Cooling liquid 3-32 V
- Safety dry air filter cartridge 3-32 R
- Radiator C (3)
- Water pump and the thermostat C (3)
- Alternator and the starter motor C (3)
- Turbo compressor C (3)
TRANSMISSION
- Gear box oil level 3-14 C
- Gear box oil 3-28 V V
-
Gear box oil filter 3-28 R R
- Silent blocks in the gear box C (3)
- Gear box controls C (3)
- Transmission pressure C (3)
- Wear of the brake pads and the brake disk C (3)
TYRES
- Tyre pressures 3-15 C C
- Wheel nut tightening 3-15 C C
- Wheel nut tightening torques 3-32 C C
-
Wheel 3-36 R
BOOM
- Boom pads 3-11 N/G (2)
- Boom 3-16 G G
- Outer boom chains MT 1840 … 3-20 N/G/C N/G/C
- Outer boom chain wear MT 1840 … 3-29 C
- Boom pad wear C (3)
- Condition of boom assembly C C (3)
- Bearings and articulation rings C (3)
- Inner boom chain wear MT 1840 … C (3)
HYDRAULIC SYSTEM
- Hydraulic oil level 3-18 C C
- Hydraulic return oil filter cartridge 3-24 R R
-
Hydraulic oil 3-24/33 C V
- Breather for the hydraulic oil tank 3-33 R
- Suction strainer for hydraulic oil tank 3-33 N
- Brake accumulator unit filter 3-33 R
- Hydraulic pump tubular filter N (3)
- Condition of hoses and flexible pipes C (3)
- Condition of cylinders (leakage, rods) C (3)
