Manitou MT 1435 EASY 75D ST3B S1 User Manual

2 - 20
DIMENSIONS AND LOAD CHART MT 1435 EASY 75D ST3B S1
A mm 1200
B
mm 3070
C
mm 1905
C1
mm 1790
D
mm 6135
D1
mm 6020
D2
mm 4859
E
mm 7335
F
mm 1960
F1
mm 1960
G
mm 384
G1
mm 367
G2
mm 380
G3
mm 355
I
mm 1160
J
mm 892
K
mm 1040
L
mm 50
N
mm 1855
O
mm 125
P2
° 34
P3
° 33
R
mm 3779
S
mm 8626
T
mm 4183
U1
mm 2452
U2
mm 2640
V
mm 5468
V1
mm 1285
V2
mm 3986
W
mm 2374
W1
mm 3793
W2
mm 1134
W3
mm 2422
Y
° 12
Z
° 114
D2
B
G2
G1
P2
D
C
W2
C1
D1
A
E
I
N
P3
G
L
Z
Y
U1
U2
F1
F
W
W1
J
W3
G3
S
V
T
V1
V2
R
O
K
647563 (22/08/2017) MT 1435/1440/1840 EASY 75D ST3B S1

Manitou MT 1435 EASY 75D ST3B S1 Specifications

General

Brand	Manitou
Model	MT 1435 EASY 75D ST3B S1
Category	Front End Loaders
Language	English
