2 - 16
CHARACTERISTICS MT 1840 EASY 75D ST3B S1
I.C. ENGINE
Type
DEUTZ TD 3.6 L4 2501-1714
Fuel
Diesel
Number of cylinders
4 in line
Suction
Supercharged
Injection system
Direct
Ignition sequence 1.3.4.2
Capacity cm
3
3621
Bore and stroke mm 98 x 120
Compression ratio 18:1
Nominal speed laden rpm 2200
Idling speed slow unladen rpm 850
Max. speed unladen rpm 2350
Power ISO/TR 3046 cv - kW 75 - 55,4
Power SAE J 1995 cv - kW 75 - 55,4
Maximum torque ISO/TR 3046 Nm 330 to 1600 rpm
Gravimetric efficiency ISO 5011 % 99,9
Type of cooling By water
Fan Puller
TRANSMISSION
Gear box
DANA
- Type Mechanical
- Forward/reverse selector Electro-hydraulic
- Torque converter DANA
- Number of forward speeds 4
- Number of reverse speeds 4
Angle gear box -
Front axle DANA
- Differential Without locking
Rear axle DANA
- Differential Without locking
Drive wheels 4RM Permanent
- Switch for 2/4 drive wheels No
Front tyres ALLIANCE
- Size 440/80-24 A325 168A8 ATG
- Pressure
bar
4,5
Rear tyres ALLIANCE
- Size 440/80-24 A325 168A8 ATG
- Pressure
bar
4,5
ELECTRIC CIRCUIT
Battery
STANDARD 12 V - 110 Ah - 900 A EN
OPTION 12 V - 180 Ah - 900 A EN
Alternator 14V - 95A
- Type ISKRA AAK3868
Starter 12 V - 3,2 kW
- Type ISKRA AZE 4668
BRAKE CIRCUIT
Service brake
Hydraulic power brake
- Type of brake Multidisk brake immersed in oil
- Type of control Foot-operated for the front and rear axles
Parking brake Low pressure brake
- Type of brake Disk on gear-box output
- Type of control Electro-hydraulic
SOUND AND VIBRATION
Sound pressure level in the driver's cab LpA
(according to standard NF EN 12053)
dB(A) 79 (cab closed) ; 00 (cab open)
Sound pressure (according to directive2009/76) dB(A) 00 (cab closed) ; 00 (cab open)
Sound pressure level ensured in the LwA environment
(according to directive 2000/14/EC modified by directive 2005/88/EC)
dB(A) 102 (measured) ; 104 (ensured)
Sound level in motion (according to directive 2009/63) dB(A)
Average weighted acceleration on driver's body
(according to standard NF EN 13059)
m/s2 1,0
The average weighted acceleration transmitted to the driver's hand/
arm system (according to standard ISO 5349-2)
m/s2 < 2,5
Standard seat vibration m/s2 00 (lightweight operator) ; 00 (heavyweight operator)
647563 (22/08/2017) MT 1435/1440/1840 EASY 75D ST3B S1
