Manitou MT 1435 EASY 75D ST3B S1 User Manual

2 - 13
HYDRAULIC CIRCUIT
Hydraulic pump
- Type
Gear pump with flow divider on 2nd casing
1st casing 2nd casing
- Capacity cm3 45 27
- Max. rating capacity unladen l/mn 106 64
- Flow rate at 1600 rpm l/mn 72 44
Filtration
- Return μm
16 16
- Suction μm 135 135
Maximum service pressure bar 270
- Telescoping circuit bar 180 / 270
- Lifting circuit bar 210 / 270
- Tilt circuit bar 270 / 200
- Stabilizers Circuit bar 270
- Tilting corrector circuit (OPTION) bar 270
- Attachment circuit (OPTION) bar 270
- Steering circuit bar 145
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device
Electronic
Lifting motions (boom retracted)
- Unladen lifting s - m/mn
16 - 23,8
- Laden lifting s - m/mn 18 - 21,2
- Unladen lowering s - m/mn 12,4 - 30,7
- Laden lowering s - m/mn 13 - 29,3
Telescoping motions (boom raised)
- Unladen extending s - m/mn
17,3 - 24,4
- Laden extending s - m/mn 18,7 - 26,4
- Unladen retracting s - m/mn 13 - 35,1
- Laden retracting s - m/mn 12,8 - 35,6
Tilting movements
- Unladen digging s - °/s
4 - 31,5
- Forward tilting unladen s - °/s 4 - 31,5
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground
(except particular conditions)
Front unladen 1 km/h 5,4
2 km/h 8,6
3 km/h 15,5
4 km/h 24,9
Rear unladen 1 km/h 5,1
2 km/h 8,1
3 km/h 15,1
4 km/h 25,6
Standard attachment TFF 35 MT1040
- Weight with forks kg 160
- Weight of forks (each one) kg 70
Rated capacity with standard attachment kg 3500
Tipping load at maximum reach on stabilisers kg 950
Distance from the centre of gravity from the load to the lug of the forks mm 500
Standard lifting height mm 13530
Lift truck weight without attachment kg 9400
Lift truck weight with standard attachment
- Unladen kg
9700
- At rated load kg 13200
Weight per axle with standard attachment (transport position)
- Front unladen kg
5460
- Rear unladen kg 4240
- Front rated load kg 11830
- Rear rated load kg 1370
Weight per axle with standard attachment (boom extended)
- Front rated load kg
9640
- Rear rated load kg 160
Contact pressure on the ground for the whole surface of each stabilizer
at maximum load when tilting
kg/cm2 5,37
Drag strain on the coupling hook
- Unladen (sliding) daN
6000
- At rated load (transmission setting) daN 7980
Pull strain with open carrier (according to standard ISO 8313) daN 7400
647563 (22/08/2017) MT 1435/1440/1840 EASY 75D ST3B S1
