2-11
HYDRAULIC CIRCUIT
Hydraulic pump
Type Gear
Capacity cm3 31,4
Max. rating capacity unladen l/mn 87,9
Flow rate at 1600 rpm l/mn 50,2
Filtration
Return μm 10
Suction μm 125
Maximum service pressure bar 235
Telescoping circuit bar 235 / 235
Lifting circuit bar 235 / 235
Tilt circuit bar 245 / 245
Attachment circuit bar 235
Steering circuit bar 140
BRAKE CIRCUIT
Service brake Non-servo hydraulic brake
Type of brake Multidisk brake immersed in oil
Type of control By foot on front axle
Parking brake Low pressure hydraulic brake
Type of brake Multidisc brake immersed in oil
Type of control Switch-operated electro-hydraulic
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (jib retracted)
Unladen lifting s - m/mn 8 - 28,3
Laden lifting s - m/mn 8 - 28,3
Unladen lowering s - m/mn 5,4 - 41,9
Laden lowering s - m/mn 5,3 - 42,7
Telescoping motions (jib raised)
Unladen extending s - m/mn 5,6 - 22,3
Laden extending s - m/mn 5,9 - 23,5
Unladen retracting s - m/mn 4,3 - 30,6
Laden retracting s - m/mn 4 - 32,9
Tilting movements
Unladen digging s - °/s 3,5 - 36,7
Forward tilting unladen s - °/s 3,6 - 35,6
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground (except particular conditions)
Front unladen 1 low km/h 7,2
1 high km/h 24,8
Rear unladen 1 low km/h 7,2
1 high km/h 24,8
Standard attachment PFB 25 N MT 1020
Weight of attachment (without forks) kg 80
Weight of forks (each one) kg 76
Rated capacity with standard attachment kg 2500
Tipping load at maximum reach on tyres kg
Distance from the centre of gravity from the load to the lug of the forks Mm 500
Standard lifting height Mm 5820
Lift truck weight without attachment kg 4485
Lift truck weight with standard attachment
Unladen kg 4710
At rated load kg 7210
Weight per axle with standard attachment (transport position)
Front unladen kg 2210
Rear unladen kg 2500
Front rated load kg 6540
Rear rated load kg 670
Weight per axle with standard attachment (jib extended)
Front rated load kg 5130
Rear rated load kg 380
Authorised gross vehicle weight daN 20000
Drag strain on the coupling hook
Unladen (sliding) daN 3485
At rated load (transmission setting) daN 4035
Pull strain with open carrier
(according to standard ISO 8313) daN 3427
647421 (22/08/2017) MT-X 625 Série 2-E3 + COMFORT
