Manitou MT-X 625 2-E3 Series User Manual

2-14
DIMENSIONS AND LOAD CHART
A
(mm)
1200
B
(mm)
2300
C
(mm)
991
C1
(mm)
928
D
(mm)
3894
D1
(mm)
3831
D2
(mm)
3275
E
(mm)
5094
F
(mm)
1492
F1
(mm)
1492
G
(mm)
240
G1
(mm)
330
G2
(mm)
253
I
(mm)
603
J
(mm)
797
K
(mm)
1015
L
(mm)
45
N
(mm)
1314
O
(mm)
125
P2
(°)
37
P3
(°)
52
R
(mm)
3150
S
(mm)
6651
T
(mm)
3935
U1
(mm)
1920
U2
(mm)
2054
V
(mm)
4700
V1
(mm)
765
V2
(mm)
3310
W
(mm)
1813
Y
(°)
12
Z
(°)
117
647421 (22/08/2017) MT-X 625 Série 2-E3 + COMFORT
