Manitou MT-X 625 2-E3 Series User Manual

2-10
TRANSMISSION
Hydrostatic pump DANFOSS
Type Variable displacement piston
Forward/reverse selector Electro-hydraulic
Number of forward speeds 2 (1 low and 1 high)
Number of reverse speeds 2 (1 low and 1 high)
Main pump
MAX./MIN. displacement cm3/rev 0 - 53
MAX. flow rate l/mn 138
Working pressure bar 350
Boost pump
Capacity cm3/rev 12
MAX. flow rate l/mn 31
Boost pressure MAX. R.P.M. bar 24 (transmission in neutral)
Hydrostatic motor DANFOSS
Type Variable displacement piston
MAX./MIN. displacement cm3/rev 30 - 110
Gear box DANA
Front axle DANA
Differential 45 % limited slip differential
Rear axle DANA
Differential Without locking
Drive wheels 4RM Permanent
Switch for 2/4 drive wheels No
Front tyres SOLIDEAL
Size 12-16,5 12PR SKS CL TUBELESS
Pressure bar 5,6
Rear tyres SOLIDEAL
Size 12-16,5 12PR SKS CL TUBELESS
Pressure bar 5,6
CHARACTERISTICS
SOUND AND VIBRATION
Level of sound pressure in the driver’s cab LpA
(according to standard NF EN 12053)
dB 75 (cab closed)
Level of sound power ensured in the LwA environment
(according to directive 2000/14/EC modified by directive 2005/88/EC)
dB
104 (measured)
104 (ensured)
Average weighted acceleration on driver’s body
(according to standard NF EN 13059)
m/s2
The average weighted acceleration transmitted to the driver’s hand/arm system
(according to standard ISO 5349-2)
m/s2 < 2,5
I.C. ENGINE
Type KUBOTA V3307
Fuel Diesel
Number of cylinders 4 in line
Suction Supercharged
Injection system Direct
Ignition sequence 1.3.4.2
Capacity cm3 3331
Bore and stroke mm 94 x 120
Compression ratio 20
Nominal rating loaded rpm 2600
Rating slow unladen rpm 895
Max. rating unladen rpm 2800
Power ISO 3046-1 cv- kW 75 - 55,4
Power SAE J 1995 cv- kW 75 - 55,4
Maximum torque ISO 3046-1 N.m 265 to 1400 rpm
Air cleaner μm 3
Type of cooling By water
Fan Puller
ELECTRIC CIRCUIT
Battery
Standard 12 V - 110 Ah - 750 A EN
Option - - - - - -
Alternator 12 V - 80 A
Type A5TA59 77B
Starter 12
V - 3 kW
Type M008T50671
647421 (22/08/2017) MT-X 625 Série 2-E3 + COMFORT
