Manitou MT-X 625 2-E3 Series User Manual

3-10
SERVICING SCHEDULE
(1): MANDATORY 500 HOUR OR 6 MONTH SERVICE
This service must be carried out after approximately the first 500 hours of service or within the 6 months following the start-up of the machine (whichever occurs
first).
(2): The I.C engine oil and oil filter must be replaced after the first 50 hours of service, then every 500 hours of service.
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY 10
HOURS OF SERVICE
EVERY 50 HOURS OF
SERVICE
EVERY 250 HOURS OF
SERVICE
EVERY 500 HOURS OF
SERVICE OR EVERY 6
MONTHS
EVERY 1000 HOURS
OF SERVICE OR EVERY
YEAR
EVERY 2000 HOURS
OF SERVICE OR EVERY
TWO YEARS
EVERY 4000 HOURS
OF SERVICE
OCCASIONALLY
I.C. ENGINE
I.C. engine oil level
3-12 C C <<< <<< <<< <<< <<< <<<
Cooling liquid level 3-12 C C <<< <<< <<< <<< <<< <<<
Fuel level 3-12 C C <<< <<< <<< <<< <<< <<<
Cyclonic pre-filter 3-13 N N <<< <<< <<< <<< <<< <<<
Dry air filter cartridge 3-16/26 R N <<< <<< R <<< <<<
Radiator cores 3-16 N N <<< <<< <<< <<< <<<
Condenser core (OPTION Air conditioning) (MT-X 625 COMFORT) 3-16 C/N C/N <<< <<< <<< <<< <<<
Alternator/fan/crankshaft belt tension 3-20 C/A C/A <<< <<< <<< <<<
Compressor belt tension (OPTION Air conditioning)(MT-X 625 COMFORT) 3-20 C/A C/A <<< <<< <<< <<<
Fuel water trap 3-20 V V <<< <<< <<< <<<
I.C. engine oil (2) 3-22 V V <<< <<< <<<
I.C. engine oil filter (2) 3-22 R R <<< <<< <<<
Fuel filter 3-23 R R <<< <<< <<<
Fuel pre-filter 3-25 R R <<< <<< <<<
Alternator/fan/crankshaft belt 3-23 R R <<< <<< <<<
Fuel tank 3-26 N <<< <<<
I.C. engine silent blocks C** <<< <<<
I.C. engine rates C** <<< <<<
Valves clearances C** C** <<< <<<
Safety dry air filter cartridge 3-28 R <<<
Cooling liquid 3-28 V <<<
Injection pump C** <<<
Injectors C** <<<
Radiator C** <<<
Water pump and the thermostat C** <<<
Alternator and the starter motor C** <<<
Turbocompressor C** <<<
Fuel circuit 3-32 P
TRANSMISSION
Hydrostatic transmission circuit pressures
C** <<<
Governing start of the hydrostatic transmission C** <<<
Hydrostatic transmission cut-off operation C** <<<
TYRES
Tyres pressure
3-13 C C <<< <<< <<< <<< <<< <<<
Wheel nuts torque 3-13 C C <<< <<< <<< <<< <<< <<<
Condition of wheels and tyres C** <<< <<<
Wheel 3-32 R
JIB
Jib pads
3-13 G* <<< <<<
Jib 3-17 G G <<< <<< <<< <<< <<<
Jib pads wear C** <<< <<<
Condition of jib unit C** <<<
Bearings and articulation rings C** <<<
HYDRAULIC
Hydraulic oil level
3-18 C C <<< <<< <<< <<< <<<
Hydraulic return oil filter cartridge 3-24 R R <<< <<< <<<
Hydraulic oil 3-24/29 C V <<<
Brake accumulator unit filter 3-29 R <<<
Speeds of hydraulic movements C** <<<
Hydraulic pump tubular filter N** <<<
Condition of hoses and flexible pipes C** <<<
Condition of cylinders (leakage, shafts) C** <<<
Hydraulic circuit pressures C** <<<
Hydraulic circuit outputs C** <<<
