50960025/CP0514 74 PRINTED IN U.S.A.
GENERAL INFORMATION
Decal locations information is provided to assist in the
proper selection and application of new decals, in the
event the original decals become damaged or the
machine is repainted.
For correct replacement of decals, compare the loca-
tion illustrations to the machine before starting to
refinish the unit. Check off each required decal using
the illustration reference number to find the part num-
ber, description and quantity in the list. Refer to the
appropriate illustrations for replacement locations.
If there is a decal on a part that is being replaced, be
sure that the decal is applied to the replacement part.
NEW DECAL APPLICATION
Before applying the new decals, surfaces must be free
from dirt, dust, grease and other foreign material. To
apply a solid-formed decal, remove the smaller portion
of the decal backing paper and apply this part of the
exposed adhesive backing to the clean surface while
maintaining proper position and alignment. Slowly
peel off the other portion of the backing paper while
applying hand pressure to smooth out decal surface. To
apply a die-cut decal, first remove the backing paper.
Then, properly orient and position the decal onto the
clean mounting surface. After the decal is firmly
applied and smoothly pressed down, remove the front
covering paper.
DECAL KITS
51200582 MT6642XT Telescopic Handler with PWP
51200583 MT6642XT Telescopic Handler without PWP
51200584 MT8044XT Telescopic Handler with PWP
51200585 MT8044XT Telescopic Handler without PWP
51200586 MT10044XT Telescopic Handler with PWP
51200587 MT10044XT Telescopic Handler without PWP
51200588 MT10055XT Telescopic Handler with PWP
51200589 MT10055XT Telescopic Handler without PWP
51200590 MT12042XT Telescopic Handler with PWP
51200591 MT12042XT Telescopic Handler without PWP
NOTE: Decals may be purchased in kits or indi-
vidually.
NOTE: Decal kits contain decals for both control
configuations. Refer to the following reference
pages to determine the correct control decals for
the machine.
PAINT FINISH
Use this list to order paint for refinishing:
808020 1 Gallon Red
808021 6 (12-oz. Spray Cans) Red
808043 1 Gallon Gun-Metal Gray
808044 6 (12-oz. Spray Cans) Gun-Metal Gray
Chapter 9
DECAL LOCATIONS
CAUTION
ALWAYS read and follow the safety precau-
tions on decals. Replace decals if they are
damaged, or if the unit is repainted. If repaint-
ing, BE SURE that all applicable decals are
affixed in their proper locations.
