PRINTED IN U.S.A. 5 50960025/CP0514
Service Capacities
Cooling System:
21.2 qts. (20.1 L), 50/50 mixture
Anti-freeze protection: -34°F (-31°C)
Pressure cap:18 psi (124 kPa)
Fuel tank: 47 gallons (178 L)
Hydraulic reservoir and system:
45 gallons (170 L)
Transmission and cooler: MT6642,
MT8044
15.6 qts. (14.8 L)
Transmission and cooler: MT10044,
MT10055, MT12042
16.4 qts. (15.5 L)
Axles: MT6642, MT8044
Differentials (2): 15.8 qts. (15 L) ea.
Hubs (4): 2.6 qts. (2.5 L) ea.
Axles: MT10044, MT10055, MT12042
Front Differential: 14.8 qts. (14.0 L)
Front Planetaries: 1.85 qts. (1.75 L) ea.
Rear Differential: 14.25 qts. (13.5 L)
Rear Planetaries: 1.85 qts. (1.75 L) ea.
Transmission
MT6642, MT8044
Type:Dana Powershift T12000
Speeds: 3 fwd / 3 rev
Torque converter:
Single-stage, dual-phase
Travel Speeds:
1st gear: 3.3 mph (5.3 km/h)
2nd gear: 7.3 mph (11.8 km/h)
3rd gear: 18.8 mph (30.3 km/h)
MT10044, MT10055, MT12042
Type: Dana Powershift T13000
Speeds: 4 forward / 3 reverse
Torque converter:
Single-stage, dual-phase
Travel speeds:
1st gear: 3.0 mph (4.8 km/h)
2nd gear: 6.5 mph (10.5 km/h)
3rd gear: 13.1 mph (21.1 km/h)
4th gear: 19.3 mph (31.1 km/h)
Axles (front and rear)
MT664242, MT8044
Type: Dana model 212HY
Drive/steer, open differential, full-time
four-wheel drive, internal SAHR parking
brake in front axle
Overall ratio: 22.67:1
MT10044, MT10055, MT12042
Type: Dana model 223
Front axle: Drive/steer, limited-slip differ-
ential with internal SAHR parking brake
Overall ratio: 26.21:1
Rear axle: Drive/steer, open differential
Overall ratio: 26.21:1
Engine
Turbocharged aspiration:
John Deere 4045T Interim Tier 4
276 cu. in. (4.5 L) displacement,
115 hp (86 kW) @ 2400 rpm
Oil capacity: 15.5 qts. (14.7 L)
In-line 4-cylinder, 4-cycle,
direct injection diesel fuel system,
in-line fuel filter w/water trap,
positive pressure lubrication,
liquid pressurized cooling system,
dry dual-element air cleaner,
spin-on oil filter.
Hydraulic System
Type: Open-center
Pump: Single-section gear type
Displacement / revolution:
3.72 cu. in. (61 cc)
Flow @ 2500 rpm: 40 gpm (151 L/min)
Main relief pressure: 3000 psi (207 bar)
Steer relief pressure: 2500 psi (172 bar)
Joystick and Parking Brake release Pressure:
350 psi (24 bar)
Hydraulic filter:
In-tank return type, 10-micron media,
replaceable element
Rated flow: 100 gpm (379 L/min)
Rated pressure: 100 psi (690 kPa)
By-pass pressure (full flow):
25 psi (172 kPa)
Hydraulic strainer:
In-tank suction, 100-micron media, replace-
able element
Rated flow: 100 gpm (379 L/min)
By-pass pressure: 3 psi (21 kPa)
