2012.12 Description - STACKY
STACKER IDENTIFICATION
As our policy is to promote a constant improvement of our products, our range of
stackers may undergo certain modications, without obligation for us to advise our
customers.
When ordering spare parts or requesting technical information, always specify the
information given on the manufacturer’s plates.
NOTE : For the owner's convenience, it is recommended that a note of these numbers
is made in the spaces provided, at the time of the delivery of the stacker.
STACKER MANUFACTURER'S PLATE (fig. A)
- Model
- Rated capacity
- Identification number
- Made in
- Model year
- Maximum lift height
TOOL MANUFACTURER’S PLATE (fig. B)
- Model
- Rated capacity
- Identification number
- Made in
HYDRAULIC UNIT (fig. C)
- Model
- Power
- Serial Number
- Year of manufacture
DRIVE UNIT (fig. D)
- Type
- Series
- Power
- Year of manufacture
For any further technical information regarding your stacker, refer to chapter :
2 - TECHNICAL CHARACTERISTICS on the following page.
MODELE
CAP. NOMINALE
CENTRE DE GRAVITE
HAUTEUR DE LEVEE
CAPACITE EFFECTIVE
MATRICULE
FABRIQUE EN
ANNEE MODELE
MASSE A VIDE
+
-
Maxi : kg
24 V
Mini : kg
A
MODELE
CAP. NOMINALE
CENTRE DE GRAVITE
MATRICULE
FABRIQUE EN
MASSE A VIDE
B
C
D
