TECHNICAL CHARACTERISTICS
CODIFICATION
Manufacturer MANITOU
Type
SK 10 FR S16 SK 10 FR D28 SK 10 LE S16 SK 10 LE D28 SK 14
CHARACTERISTICS
Mode of propulsion
Battery
Type of operation Pedestrian
Rated load capacity Q kg 1000 1000 1400
Centre of gravity of load C mm 600 500 600
Distance from fork heel to roller centreline x mm 642 653 646 689
Wheelbase y mm 1160 1190 1200
HEIGHTS
Type of mast
Simplex Duplex Simplex Duplex Simplex
Overall height (mast lowered) h1 mm 1990 2030 1990 2030 1331
Overall height (mast extended) h4 mm 2140 3400 2140 3400 1331
Lifting stroke h3 mm 1570 2740 1570 2740 818
Height of tiller arm in driving position h14 mm 850 / 1350
Height of forks in down position h13 mm 90 (+5 -0) 60 (+5 -0) 80 (+5 -0)
PERFORMANCE
Speed of travel (laden/unladen) km/h
4,2 / 4,5 4,2 / 4,5 4,5 / 5,0
Lifting speed (laden/unladen) m/s 0,14 / 0,25 0,12 / 0,20 0,1 / 0,18
Lowering speed (laden/unladen) m/s 0,16 / 0,14 0,12 / 0,10 0,1 / 0,07
Max. ramp (laden/unladen) % 3,5 / 5 3,5 / 5 5 / 8
Service brake Electromagnetic Electromagnetic Electromagnetic
DRIVE
Traction motor (S2 60 min) kW
0,3 0,5
Lifting motor (S3 10 %) kW 2 2
Type of battery as per DIN 43531/35/36,A,B,C Semi-traction Semi-traction
Battery voltage and capacity (5 hours) V/Ah 2 x 12 / 85 2 x 12 / 85
Weight of batteries (± 5 %) kg 2 x 25 2 x 25
MISCELLANEOUS
Speed control
Mosfet AC speed controller
Noise level in the operator’s ear according to
EN 12053
dB(A) < 70
EFFECTIVE DIMENSIONS
Overall length excluding tool L mm
1828 1817 1663 1652 1820
Overall width b/b2 mm 806 1100 / 1480 806
Length to the front of the forks L2 mm 678 667 713 702 670
Length to the front of the tool clamp L4 mm 750 740 750 740 820
Fork dimensions s,e,l mm 70 x (80 / 120) x 1150 80 x 40 x 950 60 x 178 x 1150
Width of fork clamp b3 mm 700 750 680
Fork spacing (outer) b5 mm 560 720 566
Support leg spacing (min / max) b4 mm 290 900 / 1280 270
Ground clearance under mast (laden) m1 mm 30 30 35 32
Ground clearance at middle of wheel-base m2 mm 20 40 22
Aisle width with pallet 800 x 1200 lengthwise Ast mm 2234 2320 2070
Turning radius Wa mm 1346 1375 1385
WEIGHT
Weight of machine in working order kg
500 620 626 650 442
WHEELS
Polyurethane front wheel Ø x width mm
200 x 80
Polyurethane rear wheel q x ( Ø x width ) mm 2 x (78 x78)
Stabiliser wheel Ø x width mm 125 x 50 100 x 40 125 x 50
Front track b10 mm 517 517
Rear track b11 mm 421 1000 / 1380 388
