14000 SERVICE MANUAL HYDRAULIC SYSTEM
2
Item Description
1 Pump EDC/Motor PCP
2 Manual Override
3 Electrical (DIN) Connector
4 Solenoid Valve
5 Manual Override (though end cap)
FIGURE 2-29
1
P966a
3
Typical Pump Installation
2
Typical Solenoid Valve Installation
P2378
4
3
5
