Right Side Components - Current Production Tier 3/4
Item Description Item Description
1 Battery Disconnect Switch 11 Air Conditioning Condenser
2 Engine Node 12 Air Conditioning Drier
3 Batteries 13 Engine Air Cooler
4 Fuel Fill Cap 14 Hydraulic Oil Cooler
5 Fuel Tank 15 Free Fall Drum Clutch/Brake (optional)
6 External Fuel Gauge 16 Free Fall Proportional Valve
7 Primary Fuel Filter 17 Enable/Disable Free Fall Handles
8 Secondary Fuel Filter 18 Drum 1 Free Fall Pressure Sender
9 Engine Coolant Filter 19 Drum 2 Free Fall Pressure Sender
10 Engine Radiator
P2430
1
3
P2372
2
4
5
6
7
12
13
11
See Section 3 for
Description of
Electrical Components
FIGURE 1-6
14COM5-2
9
P1578
15
A15886
19
17
18
16
10
14
8
To Next Page
