Manitowoc 14000 Service And Maintenance Manual

Reference Only
ELECTRIC SYSTEM 14000 SERVICE MANUAL
3-6
Published 09-10-14, Control # 065-24
Table 3-2 . Pump and Motor Values
Abbreviations
The following abbreviations are used in test voltage tables:
Pumps Hoist Motors Travel Motors
0 to 25.4 Volts (at node) 3.8 to 14 Volts (at node)
0 or 28 Volts (at node)
2
0 to 2.0 Volts (at pump) 3.8 to 14 Volts (at motor)
0 or 28 Volts (at 2-speed solenoid)
2
1 to 100 mA
1
180 mA to 600 mA
1,4
0 or 1500 mA
1
Table 3-2 Notes
1
Resistance increases as the temperature rises on the pump or motor control coil resulting in
decreased current values when measured with a meter. The listing in the table is the current range for
a 21
°C coil.
2
Travel motor control is two speed. When the travel motor control solenoid is energized, the motor is
locked in max displacement. When the motor control solenoid is de-energized, the pressure
compensator will shift the motor to min displacement. The Master Node will only de-energize the coil if
the 2-Speed Travel Switch is in the high speed position and the engine RPM is above 1500. The
pressure compensator override will begin to shift motor back to max displacement, low speed as the
closed loop pressure reaches or exceeds 3915 to 4200 PSI (270 to 290 BAR) in order to stabilize and
hold the pressure constant protecting the motor from over heating and catastrophic failure.
4
The Master Node regulates displacement of the hoist motors by the EDC control on the motor. 180
mA the coil is at rest and the motor is in max displacement. 750 mA the coil is fully energized and
the motor is in min displacement.
AC
=
Alternating Current
A/C
=
Air Conditioning
AI
=
Analog Input
AO
=
Analog Output
AUX.
=
Auxiliary
CAN
=
Controller Area Network
CANH
=
Controller Area Network - High
CANL
=
Controller Area Network - Low
CHA or CHB
=
Channel A or B
DC
=
Direct Current
DI
=
Digital Input
DO
=
Digital Output
EC
=
Encoder Control
ENC
=
Encoder Number Count
GND
=
Ground
ID
=
Identification
I/O
=
Input/Output
L.E.D.
=
Light Emitting Diode
Max.
=
Maximum
Min.
=
Minimum
M/C
=
Motor Control
N/A
=
Not Applicable
N/C
=
No Connection
NO
=
Number
NS
=
Node Select
Opt.
=
Optional
P
=
Pin
P/C
=
Pump Control
RCL
=
Rated Capacity Indicator/Limiter
V
=
Volt or Volts
VDC
=
Volts Direct Current
W
=
Wire
