Manitowoc Published 09-10-14, Control # 065-24 3-3
14000 SERVICE MANUAL ELECTRIC SYSTEM
3
FIGURE 3-2
3
2
1
5
6
7
4
Item Description
1 Radiator
2 Diesel Particulate Filter
3 Grid Heater Junction Box
4 Cover Mounting Bracket
5 Junction Box Cover
6 120 Amp Circuit Breaker
7 Contactor Relay
Grid Heater Junction
Box Wiring Diagram
M100022
M100020
M100019
